GRADE 1 Cross Bar Narrow Stile Surface Vertical Rod Exit Device
•GRADE 1 Cross Bar Narrow Stile Surface Vertical Rod Exit Device
•45-SVR Series for Panic. F45-SVR Series for Fire Exit hardware for all types of 4’ x 8’ single doors and 8’ x 8’ double doors for up to 3 hour fire labeled installations.
•Conforms to standards UL10C and UBC 7-2-1997 codes
| Finish | Aluminum (Alum), Dark Bronze Duranodic (Duro) |
|---|
| Finish | Aluminum (Alum), Dark Bronze Duranodic (Duro) |
|---|---|
| Size | LBR45-SVR-3684, LBRF45-SVR-3684 LENGTH 34 19/64” DOOR SIZE Up to 36” door width CROSS BAR LENGTH 33 17/64” LBR45-SVR-4896, LBRF45-SVR-4896 LENGTH 46 19/64” DOOR SIZE Up to 48” door width CROSS BAR LENGTH 45 9/32” |
| Part Number | 45-SVR AND F45-SVR Series |
| Fire-Rated | UL305 & UL10C Fire Exit Hardware. 3 hours |
| Mounting | Furnished with wood and machine screws. (12) Thru-Bolts are included and standard packaging on fire rated devices. |
| Usage | GRADE 1 Cross Bar Narrow Stile Surface Vertical Rod Exit Device |
| ANSI/BHMA Standard | A156.3, Grade 1 |
| Handing | Non-Handed. Reversible. |
| Latchbolt | Stainless Steel S304 material |
| ADA Compliance | Americans with Disability Act (ADA) compliant. 5lbs opening force on ADA products only |
| Dogging Feature | Allen-type key furnished standard on non-fire labeled devices |
| Warranty | LIFETIME |
