Extra Heavy Duty Mortise Locks Grade 1
•BHMA Certified Lifetime Warranty, GRADE 1
•Conforms to federal specification type 86; and to all dimensional and operational performances of ANSI A156.13-1 80, Series 1000, Extra Heavy Duty
•UL listed 3-hour rating, conforms to standards UL10C and UBC 7-2-1997
•Optional Interchangeable Core
•Rust-proof heavy duty 2 ¾” backset lock case
•Individual spring to prevent lever sag, easily reversible
•Forged brass lever handles exceed requirements of ADA (American Disability Act)
•Auxiliary latch bolt
•Armored front plate conceals lock mounting screws
•1″ throw heavy duty deadbolt with anti-saw hardened pins
•Heavy duty ¾” latch bolt with anti-friction latch, easily reversible
•Optional Electrified Locks available
•Conforms & Meets ADA Regulations
| Finish | Dark Bronze, Satin Chrome |
|---|---|
| model | NM8050 - Entry, NM8070, NM8080 - Storeroom, NM8453 - Entrance w/ Deadbolt, NM8495 - Keyed Privacy Deadbolt, NM8465 - Closet/Storeroom w/ Deadbolt, NM8473 - Dormitory w/ Deadbolt, NM8040 - Privacy, NM8440 - Privacy w/ Deadbolt, NM8445 - Privacy w/ Deadbolt & Indicator, NM8010 - Passage, NM8172 - Double Dummy |
| Finish | Satin Chrome-US26D, Dark Bronze-US10B |
|---|---|
| Part Number | NM8050, NM8070, NM8080, NM8453, NM8456, NM8495, NM8465, NM8473, NM8040, NM8440, NM8445, NM8010, NM8172 |
| Fire-Rated | UL Listed 3 hour rated , UL10C, UBC7-2-1997 |
| Usage | Lock |
| Device Type | Lock |
| Function | NM8453 – Entrance With Dead Bolt, NM8080-Storeroom, NM8050- Entry, NM8495- Keyed Privacy Deadbolt With Indicator, NM8040-Privacy, NM8010-Passage, NM8440- Privacy with Dead bolt, NM8445-Privacy with Deadbolt, Coiin turn outside & indicator, NM8172-Double Fixed Dummy, NM8465-Closetstorerrom with dead bolt, NM8473-Dormitory/Bedroom with dead bolt |
| ANSI/BHMA Standard | ANSI/BHMA -A156.13, Series 1000, Operational & Security Grade 1 Standards. Lock body conforms to Federal Specification Type 86, and all dimensional and operational performances. |
| Latchbolt | Brass, chrome plated with heavy-duty deadbolt |
| Trim | SE |
| ADA Compliance | Meets ADA Compliance |
| Warranty | Lifetime |
